t Y P E S o F d I E C U t t I n g
K I SS Cut
this is an image of a round cornered rectangle. As you can see the
corners have a radius and there is spacing between labels on the roll.
the spacing between labels allows for a perforation and will allow the
label art to bleed without affecting the next label on the roll.
Square Corner w/ a bLeed & tab
We call this a phased butt cut. We use 2 pieces of tooling to create
a small strip of label stock between each label where the artwork can
bleed. this requires additional tooling and an additional cost, but gives
you the flexibility of the square corner and the ability to bleed. Hand
application only. the excess strip will not be removed prior to shipping.
Sheeted w/ tab
A small tab of excess material left on one side of the sheet to allow
for easy removal of the label from its liner.
Square Corner w/ StoCK border
Also called butt cutting, this method uses a tool that scores the label
stock in a continuous roll. there is no space between labels and no
extra area to the roll width. the lack of spacing requires the artwork
to be set in slightly, giving the label a natural border. this technique is
great when you can’t find the exact die size you want in one of the kiss
cut programs because you can select the width you want and then pick
from a variety of available repeats. Hand application only.
U n i q U e D i e l i n e s
S11
1.5"
pages7-8
S10
1.25"
pages7-8
S8
4"
pages7-8
S7
2.75"
pages7-8
fC43
NS5
1.5" x 2.5"
pages11-12
fC44
2"
pages13-14
NS17
3.457" x 3.320"
pages11-12
NS15
1.977" x 1.787"
pages11-12
NS3
2"
pages11-12
NS6
2.125" x 2.75"
pages11-12
NS4
2.25" x 2.375"
pages11-12
NS2
1.625"
pages11-12
ff47
1.25"
pages15-16
ff52
1.5"
pages15-16
ff50
2"
pages15-16
ff49
2"
pages15-16
ff48
1.625"
pages15-16
Die Lines not shown to size.
34
don’t see
the tool size you want?
Ask your Sales Associate.
We have thousands
of tools.
